FORGED STRAP CLAMP WITH TAPPED END

Forged, Hardened & Tempered

This clamp is a forged version of above TIUC clamps available only for the most popular size M-16. Most suitable for mould clamping on Plastic Injection Moulding Machine.


MODEL SUITABLE FOR BOLT LENGTH WIDTH THICKNESS SLOT LENGTH TAPPED END N. W. Kgs.
TTFC -16 M-16 152 44 22 52 M -16 0.73
